I'm new here and just subscribed to see the pictures on this thread. Thanks to Marvey for your excellent write up - it is the best I've found on the BK-16.
In the next few months I'll be building a variant, the BK-161 which originally was designed for the FE168 Sigma but most often the FP163 was put into it. (similar to the BK-10 and BK-101 variants).
There is a German website (no affiliation with it, just an interest) that describes another form of a horn, basically a bass reflex with the port being a short horn. It goes lower in frequency and the horn is supposed only to work on the frequencies below the cutoff of the BR part. According to reports it works and it uses a shorter horn plus it uses drivers that are having a Qts of around 0.4 ~ 0.5.
